ABB MP0CAE3 SURGE SUPPRESSOR MP0CAE3

Product Code: MP0CAE3

The MP0CAE3 is a surge suppressor diode for contactor coils. Designed to reduce the maximum overvoltage peak value and to limit or even completely eliminate the high pre-damping voltage frequencies for a rated control circuit voltage between 6 ... 240 V. The surge suppressor is simply plugged onto the front of all MC1, MC2 and MCR DC operated variants.

Technical Specifications

Operating Voltage DC (V) 6
Operating Voltage Type DC
Brand ABB
Degree of Protection IP20
Dimensions (mm) 9W x 18H x 31D
Function Diode
Operational Temperature Range (°C) -40 to +55
Rated Control Circuit Voltage DC (V) 6 - 250
Rated Insulation Voltage (V) 750
Rated Operational Voltage AC (V) 6
Series M
Suitable For MC1, MC2, MCR DC operated
