RED LION PAX PROCESS INPUT METER, GREEN DISPLAY, DC POWERED PAXP0110

Product Code: PAXP0110

The product is a 1/8 DIN process input device with a 5-digit LED green display measuring 0.56" (14 mm). It accepts either a 20 mA or 10 VDC input and can be upgraded with option cards. The input power required is 11 to 36 VDC, with a nominal voltage of 24 VDC. The device is rated NEMA 4X/IP65 for protection against dust and water.

Technical Specifications

Number of Display Digits 5
Output Type Option Cards Available
Product Series PAX
Termination Screw Terminal
Brand RED LION
Dimensions (mm) 92 x 45
Display Screen Type LED - Green Characters
Mounting Type Panel Mount
Operational Temperature Range (°C) -10 to +50
Rated Supply Voltage AC/DC (V) 24 AC, 11 - 36 DC
Weight (kg) 0.29484
