ABB RCBO 6kA 1P+N 50A C CURVE TYPE A 30mA GSH201C50A30

Product Code: GSH201C50A30

The RCBO is a combined MCB/RCD that provides protection against short circuit, thermal overload, and earth leakage. It has a breaking capacity of 6kA at 230VAC and is designed for use in a 1P+N configuration. The RCBO has a current rating of 50A and follows the C curve Type A standard. With a sensitivity of 30mA, it offers reliable detection of earth faults. The RCBO is two modules wide, making it suitable for various electrical installations.

Technical Specifications

Brand ABB
AC Voltage (V) 230/240
Ambient Temperature Range (°C) -25 to 55
Current Rating (A) 50
Curve Type C Curve
Degree of Protection IP20
Dimensions (mm) 85H x 69D x 35W
Family GSH201
Icn-Rated Short Circuit Capacity (kA) 6
Mounting Type DIN Rail
No. of Poles 1P+N
Poles 1P+N
Rated Current (A) 50
Rated Frequency (Hz) 50/60
Rated Operational Voltage AC (V) 230
Rated Residual Current (mA) 30
Rated Short-Circuit Capacity - Icn (kA) 6
Residual Current Type A
Series GSH201
Standards and Approvals IEC 61009-1, GB/T 16917.1, AS/NZS 61009.1
Terminal Type Cage
Trip Curve C Curve
Type of Residual Current A
