Product Code: LCP-18

The Load Cell Protector is designed to provide protection for load cells and the measuring instrument panel mount. It has a maximum continuous voltage of 18VDC and can handle a maximum discharge current of 250A at 8/20ms. The maximum load current it can handle is 6.5A. With a voltage protection level of less than 40V at 0.25kA (8/20ms), it offers reliable protection for both 4-wire and 6-wire load cells. The protection stages are connected in series using SAD and GDT technology.

Maximum Load Current - I? (A)	6.5
Brand	NOVARIS
Connection Type	Series
Degree of Protection	IP65
Dimensions (mm)	65H x 116W x 56D
Maximum Continuous Operating Voltage MCOV DC (V)	18
Maximum Discharge Current (8/20µs) - Imax (kA)	0.25
Mounting Type	Panel
Operational Temperature Range (°C)	-40 to 85
Series	LCP
Standards and Approvals	IEC61643-21, ITU-T K.44, AS/NZS 1768, IEEE C62.41, UL497B
Voltage Protection Level - Up (kV)	< 0.04

Lightning & Surge Protection

NOVARIS LOAD CELL PROTECTOR UC=18V DC LCP-18

Product Code: LCP-18

Technical Specifications
