Product Code: IDD2-12-30

ELV Isolated Surge Diverters 2P+PE are designed for a nominal voltage of 24V AC/DC. They can handle a maximum continuous voltage of 30VAC and 36VDC. These surge diverters have a maximum discharge current of 12 kA (L-L) and 6kA (L-PE) at 8/20ms, with a nominal discharge current of 6 kA (L-L) and 3kA (L-PE) at the same time interval. The voltage protection level at 3kA is below 165V (L-L) and below 240V (L-PE). At a rate of 1kv/ms, the voltage protection level is below 130V (L-PE). These surge diverters provide both common and transverse mode protection, ensuring safety against electrical surges. They also have earth leakage current in the microamp range. The ELV Isolated Surge Diverters are designed for DIN rail mount installation.

Nominal Voltage DC (V)	24
Voltage Protection Level (1kV/µs) - Up (kV)	< 0.130 (L-PE)
Voltage Protection Level (3kA 8/20µs) - Up (kV)	< 0.165 (L-L), <0.24 (L-PE)
Brand	NOVARIS
Dimensions (mm)	36W x 70H x 95L
Maximum Continuous Operating Voltage MCOV AC (V)	30
Maximum Continuous Operating Voltage MCOV DC (V)	36
Maximum Discharge Current (8/20µs) - Imax (kA)	12 (L-L), 6 (L-PE)
Mounting Type	DIN rail
No. of Poles	2P+PE
Nominal Discharge Current (8/20µs) - In (kA)	6 (L-L), 3 (L-PE)
Nominal Voltage AC (V)	24
Series	IDD2
Weight (g)	230

Lightning & Surge Protection

NOVARIS ISOLATED SURGE DIVERTER, 24VAC/VDC, LED, IP20 IDD2-12-30

Product Code: IDD2-12-30

Technical Specifications
