Earth Fault Protection	Other
Limiting Frequency (Hz)	20
Maximum Continuous Voltage AC (V)	-
Mounting Method	On basic element
Nominal Voltage DC (V)	250
Voltage Protection Level Earth	1200
Brand	DEHN
Connection Type	Screw terminal
Degree of Protection	IP20
Dimensions (mm)	12W x 45H x 51D
Nominal Discharge Current (8/20µs) - In (kA)	10
Nominal Load Current AC - I? (A)	3
Reference No.	920389
Suitable For	Pluggable DIN Rail Mounted
Voltage Protection Level - Up (kV)	1100
Weight (g)	36.7
Weight (kg)	0.04

Lightning & Surge Protection

DEHN 4P T2 250V 10kA 8/20USE CPLUG MODULE ONLY C/W LIFECHECK BXTML4MY250
