RED LION UNMANAGED ETHERNET SWITCH, 5 PORT 105FX-SC

Product Code: 105FX-SC

Enhance your network's reach with the Red Lion SFP Transceiver, a robust singlemode module designed for long-distance data transmission up to 100km at 100Mbps. Ideal for integration into network solutions that demand reliability, this transceiver falls under the category of switches and is part of the trusted SFP series. Perfect for engineers looking to extend their network without compromising on speed or quality.

Technical Specifications

Current Consumption (mA) 270 at 24VDC
DIN Rail Width (mm) 35
No. of 100Mb Ports 1
No. of Ethernet Ports 4
Port Quantity and Type 4 x 10/100BASE-TX RJ45, 1 x 100BASE-FX
Brand RED LION
Cable Type FX Cable - Multimode
Connector Type FX Port - SC
Dimensions (mm) 89H x 38W x 90D
Mounting Type DIN Rail
Operational Temperature Range (°C) -40 to +70
Rated Operational Voltage DC (V) 10 - 30
Series SFP
Standards and Approvals FCC, EN61000-6-2, EN61000-6-2, EN61000-3-2, IEC61000-4-2, IEEE1613
Switch Type Switch - Unmanaged
