Current Consumption (mA)	<10
Gross Weight (g)	50
Net Weight (g)	20
Operation Indicator	Orange LED (indicaties when output = ON)
Output Operation	Light-ON
Relative Humidity	35 to 85%
Resistance to Shock (m/s²)	500
Response Time (ms)	<0.5
Sensing Range (m)	1
Withstand Voltage AC (V)	1000 for 1 minute
Brand	PANASONIC
Illuminance (lx)	3000
Ambient Temperature (°C)	-25 to +55
Cable Cross Section (mm²)	0.1
Cable Length (m)	2
Cable Type	2 core cabtyre
Degree of Protection	IP67
Dimensions (mm)	10W x 14.5H x 3.5D
Enclosure Material	Polyarylate
Insulation Resistance (MO)	20
Outputs	NPN
Pollution Degree	3 (Industrial Environment)
Rated Supply Voltage DC (V)	12 to 24
Sensor Type	Standard Thru-Beam Front Sensing
Storage Temperature (°C)	-30 to +70
Utilization Category	DC-12 or DC-13

Position Switches & Sensors

PANASONIC ULTRA-SLIM PHOTOELECTRIC SENSOR EX-19A
