Electromagnetic Capability |
10 V/m (80 MHz - 1 GHz), 3 V/m (1,4 GHz – 6GHz) |
|
Electrostatic Discharge (kV) |
4 kV Contact Discharge, 8 kV Air Discharge |
|
Network Configuration |
any |
|
Operating Voltage Range |
18 - 32V DC |
|
Power Output in BTU (IT)/h |
18.1 |
|
Relative Humidity |
5-95 % |
|
Resistance to Vibrations |
3.5 mm, 5–8.4 Hz, 10 cycles, 1 octave/min
1 g, 8.4–150 Hz, 10 cycles, 1 octave/min |
|
Software Configuration |
BOOTP/DHCP, HiDiscovery |
|
Software Diagnostics |
Device status indication (LEDs), Log-File, RMON (1) statistics, Simple interface statistics, Topology Discovery according to IEEE 802.1AB;(LLDP), Syslog |
|
Software Industrial Profiles |
PROFINET Protocol |
|
Software Management |
HTML5 Web-Interface, TFTP config file/firmware transfer, SNMP V1/V2/V3 |
|
Software Redundancy |
RSTP (IEEE 802.1D-2004), MRP Client |
|
Software Security |
SNMPv3 (authNoPriv), Possibility to disable each port, SSH, SSL |
|
Software Switchng |
TOS/DSCP prioritization (Mapping TOS/DSCP to 802.1D/p), QoS (4 queues), Static unicast/multicast filter entries (up to 100), Flow Control, VLAN Support |
|
Software Time Synchronization |
SNTP Client |
|
Transition Type |
2 kV Power Line, 2 kV Data Line |
|
Brand |
HIRSCHMANN |
|
Cable Length (m) |
0 - 100 |
|
Dimensions (mm) |
45.4W x 110H x 82D (w/o terminal block) |
|
Mounting Type |
DIN Rail |
|
No. of Pins |
3 |
|
Operational Temperature Range (°C) |
-40 - 60 |
|
Power Consumption (W) |
5.3 |
|
Storage Temperature Range (°C) |
-40 - 85 |
|
Surge Voltage (kV) |
Power Line: 2 kV (Line/Earth), 1 kV (Line/Line), 1 kV Data Line |
|
Terminal Type |
1 x Plug-In Terminal Block |
|
Weight (g) |
223 |
