Product Code: VS463-31/230V

The Din Contactor is a versatile electrical component designed for switching resistive loads and three-phase induction motors. It has 3 normally open (NO) contacts and 1 normally closed (NC) contact, providing flexibility in its applications. With a current rating of 63A (AC1), it can handle high power requirements. The control voltage is 230V AC/DC, allowing for compatibility with various systems. Measuring 3 modules wide, with each module having a width of 17.5mm, the Din Contactor is compact and space-efficient. It offers IP20 protection, ensuring safety against solid objects larger than 12mm but without protection against water. The Din Contactor is specifically designed for DIN Rail mounting, making installation quick and easy. It is suitable for a wide range of applications including heating, lighting, hot water systems, and storage heating. Overall, the Din Contactor provides reliable performance and versatility in controlling electrical circuits in industrial or commercial settings.

Brand	ELKO
Degree of Protection	IP20
Dielectrical Strength (kV)	4
Dimensions (mm)	53.3W x 84H x 60D
Mounting Type	DIN Rail
No. of Modules - Width 17.5 mm	3
No. of Normally-closed Contacts	1
No. of Normally-open Contacts	3
No. of Poles	4
Operational Temperature Range (°C)	-5 to 55
Rated Insulation Voltage (V)	440
Rated Operational Current AC-1 (A)	63
Rated Supply Voltage AC/DC (V)	230
Series	VS
Standards and Approvals	IEC 60947-4-1, IEC 60947-5-1, IEC 61095, EN 60947-4-1, EN 60947-5-1, EN 61095, EN 60947-1
Storage Temperature Range (°C)	-30 to 80
Weight (kg)	0.4

Contactors

ELKO DIN CONTACTOR, 4P, 63A-AC13NO+1NC, 230V AC/DC3 MOD. WIDE , DIN MTG. VS463-31/230V

Product Code: VS463-31/230V
