ABB MACL101AT AUXILIARY CONTACT BLOCK MACL101AT

Product Code: MACL101AT

The MACL101AT is an auxiliary contact for side mounting with 1NC contact and screw terminals. Auxiliary contacts are used for the operation of auxiliary circuits and control circuits. The auxiliary contact meets the requirements of EN 50012.

Technical Specifications

Rated Operational Current AC-15 230V (A) 6
Brand ABB
Auxiliary Contacts 1NC
Connection Type Screw Connection
Degree of Protection IP20
Dimensions (mm) 9.8W x 42.5H x 56D
Model Clip-on
Mounting Type Side Mount
No. of Normally-closed Contacts 1
No. of Poles 1
Operational Temperature Range (°C) -40 to +55
Rated Frequency (Hz) 50/60
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 750
Rated Operational Voltage AC (V) 690
Series M
Suitable For MC1, MC2 equipped with Screw terminals
Terminal Type Screw
