RED LION GRAPHITE STRAIN GAGE MODULE GMSG11R0

The Red Lion E3 I/O Module is a versatile component for automation systems, offering up to 34 mixed I/O points to accommodate a variety of industrial applications. Designed for PLCs within the E3 series, this module accepts a power input range of 10-30 VDC with a nominal range of 12-24 VDC and an inrush current of 5 A. Connectivity options include dual Ethernet ports with 10/100Base-T(X) RJ45 interfaces and a single RS-485 serial port featuring a non-isolated, half-duplex screw block configuration. For input/output flexibility, the module supports discrete inputs with voltage ranges from both DC (10-30 VDC) and AC (60-140 VAC), alongside discrete outputs compatible with similar DC or combined VDC/AC voltages. Analog input capabilities are broad, accepting signals from 4-20 mA, 0-10 VDC, RTDs, thermocouples, and up to 250 mV. Analog outputs are standardized at a range of 4-20 mA. This robust module is engineered to meet the demands of complex automation tasks while ensuring reliable performance and connectivity in industrial settings.
