ABB ESB25-13N-14 INSTALLATION CONTACTOR (NC) 25 A - 1 NO - 3 NC - 12 V - CONTROL CIRCUIT 400 HZ ESB2513N14

Product Code: ESB2513N14

The ESB25..N installation contactors are used to control single and three-phase loads up to 25 A and can be operated by AC or DC. These contactors are made for use in household applications as well as in industrial environments. The following benefits are provided: Hum-free operation, low power consumption and integrated overvoltage protection. Various contact combinations and accessories are available.

Technical Specifications

Built-in Depth (mm) 58
Excitation Voltage Type AC/DC
Hum-free Yes
Operating Voltage Type AC/DC
Rated Control Circuit Voltage (V) 12
Rated Operational Current (A) 25
Brand ABB
Contacts 1NO, 3NC
Degree of Protection IP20
Dimensions (mm) 36W X 85H X 65D
Mounting Type DIN Rail
No. of Normally-closed Contacts 3
No. of Normally-open Contacts 1
No. of Poles 4
Pollution Degree 3
Rated Control Circuit Voltage AC/DC (V) 12
Rated Impulse Withstand Voltage (kV) 6
Rated Insulation Voltage (V) 500
Rated Operational Current AC-1 (A) 25
Rated Operational Voltage AC (V) 400
Rated Operational Voltage DC (V) 220
Standards and Approvals IEC/EN 60947-1, IEC/EN 60947-4-1, IEC/EN 61095
Terminal Type Screw Terminals
Utilization Category AC-1 According to EN IEC 60947-4-1
Width in Number of Modular Spacings 2
