Product Code: 942 106-999-003

The Hirschmann RSPM20 is a robust media module designed for network solutions, falling under the category of switch modules. This unit features eight RJ45 ports split across Port A and Port B, each offering four 100 Mbit/s twisted pair (TX) connections for reliable data transmission. Engineered to operate within a temperature range of 0°C to +60°C, it meets various regulatory compliances including CE, FCC, and EU Safety standards. The RSPM20 series is tailored for engineers seeking high-performance networking hardware that can withstand demanding industrial environments.

Maximum Temperature (°C)	60
Minimum Temperature (°C)	0
No. of 100Mb Ports	8
No. of Ethernet Ports	8
Nominal Power (W)	2
Brand	HIRSCHMANN
Degree of Protection	IP30
Mounting Type	DIN Rail
No. of Ports	8 x Fast Ethernet RJ45
Operational Temperature Range (°C)	0 to +60
Power Consumption (W)	4
Series	RSPM20
Standards and Approvals	CE, FCC, RCM, EN61131, EN60950
Suitable For	RSPE Switches

Ethernet Switches

HIRSCHMANN MEDIA MODULE 942 106-999-003

Product Code: 942 106-999-003
