Electromagnetic Capability |
10 V/m (80-3000 MHz) |
|
Electrostatic Discharge (kV) |
4 kV Contact Discharge, 8 kV Air Discharge |
|
Frequency Range (Hz) |
50 - 60 |
|
Maximum Temperature (°C) |
50 |
|
Minimum Temperature (°C) |
0 |
|
Network Configuration |
any |
|
No. of Ethernet Ports |
16 |
|
No. of Fiber Ports |
4 |
|
Nominal Power (W) |
35 |
|
Operating Voltage Range |
100 - 240 V AC |
|
Port Quantity and Type |
16 x 10/100/1000BASE-TX RJ45 PoEPlus, 4 x 10/100/1000BASE-TX RJ45 or 100/1000BASE-FX SFP |
|
Power Output in BTU (IT)/h |
119 |
|
Rated Maximum Operational Voltage AC (V) |
240 |
|
Rated Minimum Operational Voltage AC (V) |
110 |
|
Relative Humidity |
10-95 % |
|
Resistance to Vibrations |
3.5 mm, 5–8.4 Hz, 10 cycles, 1 octave/min
1 g, 8.4–150 Hz, 10 cycles, 1 octave/min |
|
Software Configuration |
AutoConfiguration Adapter ACA11 Limited Support (RS20/30/40, MS20/30), Automatic Configuration Undo (roll-back), BOOTP/DHCP Client with Auto-Configuration, DHCP Server: per Port, AutoConfiguration Adapter ACA21/22 (USB), HiDiscovery, DHCP Relay with Option 82, Command Line Interface (CLI), CLI Scripting, Full-featured MIB Support, Web-based Management, Context-sensitive Help |
|
Software Diagnostics |
Management Address Conflict Detection, Signal Contact, Device Status Indication, LEDs, Syslog, Port Monitoring with Auto-Disable, Link Flap Detection, RMON (1,2,3,9), Port Mirroring 1:1, System Information, Self-Tests on Cold Start, Copper Cable Test, SFP Management, Configuration Check Dialog |
|
Software Industrial Profiles |
EtherNet/IP Protocol, PROFINET IO Protocol |
|
Software Level |
Software Layer 2 Professional |
|
Software Management |
Dual Software Image Support, TFTP, LLDP (802.1AB), LLDP-MED, SSHv1, SSHv2, V.24, HTTP, HTTPS, Traps, SNMP v1/v2/v3, Telnet |
|
Software Miscellaneous |
PoE (802.3AF), PoE+ (802.3AT), PoE+ Manual Power Management, Manual Cable Crossing |
|
Software Redundancy |
Advanced Ring Configuration for MRP, HIPER-Ring (Manager), HIPER-Ring (Ring Switch), Fast HIPER-Ring, Link Aggregation with LACP, Media Redundancy Protocol (MRP) (IEC62439-2), Redundant Network Coupling, RSTP 802.1D-2004 (IEC62439-1), MSTP (802.1Q), RSTP Guards, RSTP over MRP |
|
Software Security |
IP-based Port Security, MAC-based Port Security, Port-based Access Control with 802.1X, Guest/unauthenticated VLAN, RADIUS VLAN Assignment, Multi-Client Authentication per Port, MAC Authentication Bypass, Access to Management restricted by VLAN, HTTPS Certificate Management, Restricted Management Access, Appropriate Use Banner, SNMP Logging, Local User Management, Remote Authentication via RADIUS |
|
Software Switchng |
Disable Learning (hub functionality), Independent VLAN Learning, Fast Aging, Static Unicast/Multicast Address Entries, QoS / Port Prioritization (802.1D/p), TOS/DSCP Prioritization, Egress Broadcast Limiter per Port, Flow Control (802.3X), Jumbo Frames, VLAN (802.1Q), GARP VLAN Registration Protocol (GVRP), Double VLAN Tagging (QinQ), Voice VLAN, GARP Multicast Registration Protocol (GMRP), IGMP Snooping/Querier (v1/v2/v3) |
|
Software Time Synchronization |
PTPv2 Transparent Clock two-step, PTPv2 Boundary Clock, Buffered Real Time Clock, SNTP Client, SNTP Server |
|
Transition Type |
2 kV power line, 4 kV data line |
|
Brand |
HIRSCHMANN |
|
Cable Length (m) |
0 - 100 |
|
Degree of Protection |
IP20 |
|
Dimensions (mm) |
448W x 44H x 345D |
|
Mounting Type |
19" Control Cabinet |
|
No. of Pins |
2 |
|
Operational Temperature Range (°C) |
0 - 50 |
|
Power Consumption (W) |
35 |
|
Rated Operational Voltage AC (V) |
100 - 240 |
|
Series |
MACH104 |
|
Standards and Approvals |
EN50121-4 |
|
Surge Voltage (kV) |
Power Line: 2 kV (Line/Earth), 1 kV (Line/Line), 4 kV Data Line |
|
Switch Type |
Switch - Managed |
|
Terminal Type |
1 x Terminal Block 2-pins, contact manually or automatically (max. 1 A, 24 V DC or 24 V AC) |
|
Weight (g) |
4500 |
