W66 Industrial IP66 Switchgear

IPD UNSWITCHED SOCKET 3 PHASE 4 ROUND PINS 32A 500V LESS BASE, IP66 W66US432LB

Product Code: W66US432LB

Three phase unswitched socket with 4 round pins and without base, IP66. Current rating at 32A, voltage rating at 500V. Max cable area 16mm² and W66B1 base is required.

Technical Specifications

Brand IPD
Back Box Included No
Cover Style Light Grey
Degree of Protection IP66
Dimensions (mm) 101W x 101H x 91D
Gland Entries 1 x M32, 2 x M25
Material Polycarbonate
Maximum Cable Cross Section (mm²) 16
No. of Phases 3
No. of Pins 4
Pin Type Round
Rated Current (A) 32
Rated Voltage AC/DC (V) 500
Standards and Approvals AS3123
