STAHL 9182/20-50-12S TEMPERATURE TRANSMITTER 160552

Product Code: 160552

9182 series temperature transmitters for field circuits can be used to connect temperature sensors and potentiometers. They are easy to configure for virtually any sensor type by means of software or a DIP switch. These sensor types include Pt100 sensors, thermocouples and potentiometers. Variants with a trip amplifier function allow the input signal to be analyzed using two independent electronic contacts.

Technical Specifications

Maximum Power (mW) 32
Maximum Voltage (V) 6.5
No. of Channels 2
Brand STAHL
Certifications ATEX (BVS), Brazil (ULB), Canada (FM), China (NEPSI), IECEx (BVS), India (PESO), Korea (KTL), USA (FM), USA (UL)
Connection Type Screw Terminal
Degree of Protection IP30
Material Polyamide (Enclosure)
Maximum Current (A) 0.0197
Weight (kg) 0.195
