Maximum Actuating Speed (m/s)	0.2
Maximum Fuse Rating	6 A gG D-fuse
Maximum Latching Force (N)	400
Minimum Ambient Temperature (°C)	-25
Minimum Latching Force (N)	150
Minimum Positive Break Force (N)	15
No. of Actuating Directions	1
No. of Auxiliary Contacts	1
No. of Doors	1 (Guard Door)
No. of Safety Contacts	3
Positive Break Travel (mm)	5
Rated Control Voltage AC/DC (V)	24
Rated Operational Current AC-15 (A)	4
Rated Operational Current DC-13 (A)	1
Rated Operational Voltage AC-15 (V)	230V AC
Rated Operational Voltage DC-13 (V)	24V DC
Release Type	Manual
Sensor Height (mm)	100
Sensor Length (mm)	80
Sensor Width (mm)	172
Switching Element	NO Contact, NC Contact
Switching Principle	Slow Action
Termination	Screw Terminals M20 x 1.5
Thermal Test Current (A)	6
Utilisation Category	DC-13
Brand	SCHMERSAL
Contact Material	Silver
Degree of Protection	IP67
Enclosure Coating Material	Painted
Holding Force (N)	3500
Housing Material	Aluminium
Maximum Ambient Temperature (°C)	50
Maximum Cable Cross Section (mm²)	2 x 2.5
Minimum Cable Cross Section (mm²)	2 x 0.75
Minimum Mechanical Life	1000000 Operations
Power Consumption (W)	10
Rated Impulse Withstand Voltage (kV)	4
Rated Insulation Voltage (V)	250
Standards and Approvals	EN IEC 60947-5-1, EN ISO 13849-1

Safety Interlocks

SCHMERSAL AZM 415-11/02ZPKTE 24VAC/DCSOLENOID INTERLOCK 101193002
