IDEC PLUG-IN RELAY WITH INDICATOR SPDT 110VDC 10A RH1B-ULDC110

Product Code: RH1B-ULDC110

The IDEC RH1B-ULDC110 is a compact power relay designed for efficient operation within electrical systems. It features an SPDT configuration with a 110VDC coil voltage and a high switching capacity of 10A. The relay includes blade style terminals for secure connections and an LED indicator for visual status confirmation. Its space-saving design makes it ideal for applications where panel space is at a premium, without compromising on power or performance.

Technical Specifications

Operating Humidity 45 to 85% RH (no condensation)
Brand IDEC
Series RH
Operational Temperature Range (°C) -25 to +50
Coil Voltage DC (V) 110
Contact Configuration SPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 1P
Rated Current (A) 10
Relay Type RH1 1PDT Relay with LED indicator
Suitable Base SH1B-05C
Terminal Type Blade
Weight (g) 24
