Product Code: RH1B-ULD-DC24

The IDEC RH1B-ULD-DC24 is a compact power relay designed for efficient space utilization and high-performance switching. This SPDT relay operates with a 24VDC coil voltage and can handle a switching current of up to 10A. It features blade style terminals for easy connection, along with an LED indicator and diode for status visualization. With its robust contact capacity and high switching capability, this relay is ideal for various applications requiring reliable power control.

Brand	IDEC
Coil Voltage DC (V)	24
Contact Configuration	SPDT
Contact Material	Silver cadmium oxide
Insulation Resistance (MO)	100
Minimum Electrical Life	200,000 operations
Minimum Mechanical Life	50,000,000 operations
No. of Poles	1P
Operating Humidity	45 to 85% RH (no condensation)
Operational Temperature Range (°C)	-25 to +50
Rated Current (A)	10
Relay Type	RH1 1PDT Relay with LED indicator & diode
Series	RH
Suitable Base	SH1B-05C
Terminal Type	Blade
Weight (g)	24
