Product Code: RJ1S-CL-D110

The IDEC RJ1S-CL-D110 is a Slim Line Power Relay designed for high-performance and durability. It features an SPDT configuration and operates with a 110VDC coil voltage, capable of switching currents up to 12A. The relay's compact design, at only 12.7mm in width, includes a non-polarized LED indicator for easy status monitoring. Engineered for both excellent electrical and mechanical longevity, this relay is an ideal choice for space-conscious applications requiring reliable power switching.

Brand	IDEC
Coil Voltage DC (V)	110
Contact Configuration	SPDT
Contact Material	Silver-nickel alloy
Degree of Protection	IP40
Dielectrical Strength (kV)	Between Contact and Coil: 5, Between Contacts of the Same Pole: 1
No. of Poles	1P
Operational Temperature Range (°C)	-40 to +70
Rated Current (A)	12
Relay Type	RJ1S 1PDT Relay with LED indicator
Series	RJ
Suitable Base	SJ1S-07LW
Terminal Type	Plug-in
Weight (g)	19
