IDEC SLIM LINE PLUG-IN RELAY DPDT 24VDC 8A WITH LED

Product Code: RJ2S-CL-D24

The IDEC Slim Line Power Relay is a compact, plug-in RJ Series DPDT relay with a 24VDC coil voltage and an 8A switching current capacity. It features a highly visible indicator LED for easy status monitoring and is designed with two poles for effective power control. Its small footprint makes it suitable for space-constrained applications, while its robust construction ensures long-term reliability and a large switching capacity.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 24
Contact Configuration DPDT
Contact Material Silver-nickel alloy
Degree of Protection IP40
No. of Poles 2P
Operating Humidity 5 to 85% RH (no condensation)
Operational Temperature Range (°C) -40 to +70
Rated Current (A) 8
Relay Type RJ2S 2PDT Relay with LED indicator
Series RJ
Switching Voltage (V) 250 AC / 125 DC
Terminal Type Blade
