IDEC SLIM LINE PLUG-IN RELAY DPDT 110VDC 8A WITH LED

Product Code: RJ2S-CL-D110

The IDEC Slim Line Power Relay is a compact, high-capacity relay suitable for space-constrained applications. It features a DPDT configuration and operates with a 110VDC coil voltage, capable of switching currents up to 8A. The relay includes a highly visible indicator LED and boasts excellent durability, ensuring reliable performance with its large switching capacity.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 110
Contact Configuration DPDT
Contact Material Silver-nickel alloy
Degree of Protection IP40
No. of Poles 2P
Operating Humidity 5 to 85% RH (no condensation)
Operational Temperature Range (°C) -40 to +70
Rated Current (A) 8
Relay Type RJ2S 2PDT Relay with LED indicator
Series RJ
Switching Voltage (V) 250 AC / 125 DC
Terminal Type Blade
