IDEC PLUG-IN RELAY WITH INDICATOR & DIODE DPDT 48VDC 10A RH2B-ULD-DC48

Product Code: RH2B-ULD-DC48

The IDEC RH2B-ULD-DC48 is a compact, high-capacity plug-in relay designed for efficient operation. This DPDT relay operates with a 48VDC coil voltage and supports a 10A switching current. It features blade-style terminals for secure connections, an LED indicator for status visualization, and an integrated diode for circuit protection. Its space-saving design does not compromise on power, offering robust performance in a compact form factor.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 48
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator & diode
Series RH
Suitable Base SH2B-05C
Terminal Type Blade
Weight (g) 37
