IDEC PLUG-IN RELAY WITH INDICATOR DPDT 240VAC 10A RH2B-ULC-AC240V

Product Code: RH2B-ULC-AC240V

The IDEC RH2B-ULC-AC240V is a compact, high-capacity plug-in relay designed for efficient power switching. It features a DPDT configuration with a 240VAC coil voltage and a 10A switching current capability. Equipped with blade style terminals, this relay includes an LED indicator and check button for easy status verification and testing. Its space-saving design does not compromise on performance, offering reliable operation with its robust contact capacity and high switching capabilities.

Technical Specifications

Brand IDEC
Coil Voltage AC (V) 240
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator & check button
Series RH
Suitable Base SH2B-05C
Terminal Type Blade
Weight (g) 37
