IDEC RELAY DPDT 240VAC 10A RH2B-UAC220-240

Product Code: RH2B-UAC220-240

The IDEC RH2B-UAC220-240 is a compact power relay from the RH2 Series, designed for efficient switching with a DPDT configuration and a 240VAC coil voltage. It offers a 10A switching current capacity and utilizes blade-style terminals for secure connections. Its compact size ensures it saves space while maintaining high performance in power applications.

Technical Specifications

Brand IDEC
Coil Voltage AC (V) 240
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay
Series RH
Terminal Type Blade
Weight (g) 37
