IDEC RELAY DPDT WITH INDICATOR 12VDC 10A RH2B-ULDC12

Product Code: RH2B-ULDC12

The IDEC RH2B-ULDC12 is a compact power relay from the RH2 Series, featuring a DPDT configuration with a 12VDC coil voltage and a 10A switching current. It includes blade-style terminals for easy connection and an LED indicator for status visualization. Designed to save space while providing robust power handling capabilities, this relay is suitable for various applications requiring reliable switching performance.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 12
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator
Series RH
Terminal Type Blade
Weight (g) 37
