IDEC PLUG-IN RELAY WITH INDICATOR & DIODE DPDT 12VDC 10A RH2B-ULD-DC12

Product Code: RH2B-ULD-DC12

The IDEC RH2B-ULD-DC12 is a compact DPDT plug-in relay designed for efficient power switching. It operates with a 12VDC coil voltage and supports a 10A switching current, ensuring high-capacity control. The relay features blade-style terminals for easy installation, an LED indicator for status visualization, and an integrated diode for circuit protection. Its space-saving design makes it suitable for applications where panel space is at a premium.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 12
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator & diode
Series RH
Suitable Base SH2B-05C
Terminal Type Blade
Weight (g) 37
