IDEC RELAY DPDT 12VDC 10A RH2B-UDC12

Product Code: RH2B-UDC12

The IDEC RH2B-UDC12 is a compact power relay from the RH2 Series, designed for efficient switching with a 10A capacity. It features a DPDT configuration and operates on a 12VDC coil voltage. The relay's blade-style terminals ensure easy installation, while its small footprint makes it ideal for applications where space is at a premium. This relay combines reliable performance with a design that conserves valuable panel space.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 12
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay
Series RH
Terminal Type Blade
Weight (g) 37
