IDEC PLUG-IN RELAY WITH INDICATOR DPDT 12VAC 10A RH2B-ULAC12

Product Code: RH2B-ULAC12

The IDEC RH2B-ULAC12 is a compact, high-capacity plug-in relay designed for efficient power switching. It features a DPDT configuration with a 12VAC coil voltage and can handle up to 10A of switching current. The relay is equipped with blade-style terminals for easy installation and an LED indicator for status visualization. Its space-saving design does not compromise on performance, offering robust switching capabilities suitable for various applications.

Technical Specifications

Brand IDEC
Coil Voltage AC (V) 12
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator
Series RH
Suitable Base SH2B-05C
Terminal Type Blade
Weight (g) 37
