Relays

IDEC PLUG-IN RELAY WITH INDICATOR & DIODE DPDT 125VDC 10A RH2B-ULD-DC125

Product Code: RH2B-ULD-DC125

The IDEC RH2B-ULD-DC125 is a compact power relay designed for efficient operation with a 125VDC coil voltage and 10A switching current. This DPDT relay features blade style terminals, an LED indicator, and a diode for enhanced functionality. Its space-saving design does not compromise on power, offering high contact and switching capacities suitable for various applications.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 125
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator & diode
Series RH
Suitable Base SH2B-05C
Terminal Type Blade
Weight (g) 37
