IDEC RELAY DPDT WITH INDICATOR 110VAC 10A RH2B-ULAC110

Product Code: RH2B-ULAC110

The IDEC RH2B-ULAC110 is a compact power relay from the RH2 Series, featuring a DPDT configuration with an LED indicator for easy status monitoring. It operates with a 110VAC coil voltage and can handle a switching current of up to 10A. The relay's blade style terminals ensure secure connections while its compact size facilitates space-saving installation. This relay is designed for efficient power management in various applications.

Technical Specifications

Brand IDEC
Coil Voltage AC (V) 110
Contact Configuration DPDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
No. of Poles 2P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH2 2PDT Relay with LED indicator
Series RH
Terminal Type Blade
Weight (g) 37
