IDEC RELAY, 4PDT, 12V DC, 10A WITH INDICATOR AND DIODE RH4B-LD-DC12V

Product Code: RH4B-LD-DC12V

The IDEC RH4B-LD-DC12V is a compact 4PDT relay designed for efficient power management in electrical circuits. It operates on a 12V DC coil voltage and can handle up to 10A of contact capacity. This miniature power relay comes equipped with an indicator and diode, ensuring clear status visibility and protection against voltage spikes. Its small footprint allows for space-saving installation, making it suitable for various applications where high-capacity switching is required within limited space.

Technical Specifications

Brand IDEC
Contact Resistance (mO) 50
Operating Time 25ms
Resistance to Shock (m/s²) 1000
Resistance to Vibrations 10 to 55Hz
Coil Voltage DC (V) 12
Contact Material Silver Cadmium Oxide
Contacts 4PDT
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000
Minimum Mechanical Life 50,000,000
No. of Poles 4
Operating Humidity 45 to 85%
Power Consumption (W) 1.5
Weight (g) 74
