IDEC RELAY, 4PDT, 12V AC, 10A RH4B-UAC12

Product Code: RH4B-UAC12

  • Compact power type relays Miniature power relays with a large capacity 10A contact capacity Compact size saves space
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Operating Humidity 45 to 85%
Terminal Shape Blade Terminal
Brand IDEC
Product Type Power
IPD Product Catalogue V17 https://resources.ipd.com.au/catalogue/product-catalogue-v17
Coil Voltage AC (V) 12
Contact Material Silver Cadmium Oxide
Contact Resistance (mO) 50
Contacts 4PDT
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000
Minimum Mechanical Life 50,000,000
No. of Poles 4
Operating Time 25ms
Power Consumption (W) 1.5
Resistance to Shock (m/s²) 1000
Resistance to Vibrations 10 to 55Hz
Weight (g) 74

Description

The IDEC RH4B-UAC12 is a compact, high-capacity 4PDT relay designed for efficient space utilization. It operates with a 12V AC coil and can handle up to 10A of contact capacity. This miniature power relay is ideal for applications where space is at a premium without compromising on power.
