IDEC PLUG-IN RELAY 3PDT 24VDC 10A RH3B-UDC24

Product Code: RH3B-UDC24

The IDEC RH3B-UDC24 is a compact power relay from the RH3 Series, designed for efficient space utilization and high-performance switching. It features a 3PDT configuration with a 24VDC coil voltage and can handle a switching current of up to 10A. The relay is equipped with blade style terminals for secure connections. Its compact size combined with a robust 10A contact capacity makes it suitable for various applications requiring reliable power management.

Technical Specifications

Brand IDEC
Coil Voltage DC (V) 24
Contact Configuration 3PDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 3P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH3 3PDT Relay
Series RH
Suitable Base SH3B-05C
Terminal Type Blade
Weight (g) 50
