IDEC PLUG-IN RELAY 3PDT 12VAC 10A RH3B-UAC12

Product Code: RH3B-UAC12

The IDEC RH3B-UAC12 is a compact power relay from the RH3 Series, designed for efficient space utilization and robust performance. This 3PDT plug-in relay operates with a 12VAC coil voltage and supports a switching current of up to 10A. It features high switching capacity with blade style terminals for secure connections, making it suitable for various applications requiring reliable power control.

Technical Specifications

Brand IDEC
Coil Voltage AC (V) 12
Contact Configuration 3PDT
Contact Material Silver cadmium oxide
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000 operations
Minimum Mechanical Life 50,000,000 operations
No. of Poles 3P
Operating Humidity 45 to 85% RH (no condensation)
Operational Temperature Range (°C) -25 to +40
Rated Current (A) 10
Relay Type RH3 3PDT Relay
Series RH
Suitable Base SH3B-05C
Terminal Type Blade
Weight (g) 50
