IDEC RELAY, 3PDT, 110V DC, 10A WITH INDICATOR RH3B-ULDC110

Product Code: RH3B-ULDC110

The IDEC RH3B-ULDC110 is a 3PDT relay designed for efficient operation in power applications. It features a 10A contact capacity and operates on 110V DC with an integrated indicator for easy status monitoring. Its compact design ensures space-saving installation, making it ideal for applications where panel space is at a premium. This miniature power relay combines large capacity switching with a small footprint.

Technical Specifications

Brand IDEC
Contact Resistance (mO) 50
Operating Time 25ms
Resistance to Shock (m/s²) 1000
Resistance to Vibrations 10 to 55Hz
Terminal Shape Blade Terminal
Coil Voltage DC (V) 110
Contact Material Silver Cadmium Oxide
Contacts 3PDT
Insulation Resistance (MO) 100
Minimum Electrical Life 200,000
Minimum Mechanical Life 50,000,000
No. of Poles 3
Operating Humidity 45 to 85%
Power Consumption (W) 1.5
Weight (g) 50
