Product Code: POE.8AT-DC1

The DC 48-56V input power supply provides reliable and efficient power to the device. With 8x 30W ports, it supports high-power devices according to IEEE 802.3at standards. The compact design with a width of only 39mm allows for easy installation in tight spaces. It offers a fast data transfer rate of 1000Mbps, ensuring smooth and seamless connectivity. The temperature range of -25°C to +70°C ensures reliable operation even in extreme conditions. The device supports plug & play installation and can be conveniently mounted on a DIN rail.

Conformal Coating	No
Country of Origin	Czech Republic
E Classification	PoE Injector
Efficiency	97.30%
Input Voltage Range DC (V)	48, 56
Integrated Decoupling Function	No
Maximum Input Voltage DC (V)	56
Minimum Input Voltage DC (V)	48
Output Current Range (A)	0.63 - 0.63
Output Power (W)	240
Output Voltage (V)	48-56
Use In Crosslinking	Yes
Brand	PULS
Connection Type	Plug connector, RJ45 Ethernet
Customs Tariff Number	85043121
Degree of Protection	IP20
Dimensions (mm)	39W x 128H x 117D
Family	DIMENSION
Material	Metal
Mounting Type	DIN Rail
Operational Temperature Range (°C)	-25 to 70
Power Loss (W)	6.4
Range	DIMENSION
Rated Current (A)	0.63
Series	PoE series
Standards and Approvals	EU Declaration of Conformity, UK Declaration of Conformity
Warranty Period (Months)	36
Weight (g)	380

Industrial Power Supplies

PULS POE INJECTOR 48V, 0.6A 8 PORTS POE.8AT-DC1

Product Code: POE.8AT-DC1

Technical Specifications
