Product Code: PISA-B-812-B1

The product features eight current controlled outputs with adjustable output currents for each channel. It allows for selective tripping of overloaded channels and is compatible with large capacitive loads. The output currents are displayed live on an LED matrix. The device can be reset remotely orVia push-buttons. It also has a common alarm signal for tripped channels. Parameter settings can be locked using a PIN-code. Each individual output has an ON/OFF feature. The product also offers easy wiring with distribution terminals for the negative pole.

Conformal Coating	No
Country of Origin	Czech Republic
DC Input Current at No Load	40
E Classification	E-CS06
Input Voltage Range DC (V)	24
Maximum Input Voltage DC (V)	30
Minimum Input Voltage DC (V)	19.2
Output Voltage (V)	24
Power Loss No Load (W)	1
Required DC Input Voltage To Switch On Outputs (V)	19
Turn-on Delay Of Outputs (ms)	750
Use In Crosslinking	Yes
Brand	PULS
Connection Type	Push-in clamps
Customs Tariff Number	85363010
Degree of Protection	IP20
Dimensions (mm)	52W x 124H x 130D
Family	PISA
Material	Metal
Mounting Type	DIN Rail
Operational Temperature Range (°C)	-25 to 70
Range	PISA
Rated Current (A)	40
Series	PISA-B series
Standards and Approvals	EU Declaration of Conformity, IEC 61010-2-201 CB Scheme, IEC 62368-1 CB Scheme, UL 2367, UL 61010-2-201 Canada, UL 61010-2-201 USA, UK Declaration of Conformity
Warranty Period (Months)	36
Weight (g)	370

Industrial Power Supplies

PULS ELECTRONIC CIRCUIT BREAKER 24V, 40A PISA-B-812-B1
