Brand	ABB
Accuracy Class	Active Energy
I/O Option	4 programmable I/O
Meter Type	Digital Purchase/Supply
Net Weight (g)	355
Number of Counter Positions	9
Power Loss (VA)	28
Pulse Output Rate	1 … 999999
Realtime Clock	57
Sub-Function	RTS
Accuracy	±0.5%
Communication	Modbus TCP/IP, Bluetooth
Current Rating (A)	5
Degree of Protection	IP20
Dimensions (mm)	96 X 96 X 78
Display Screen Type	Digital
Mounting Type	DIN-Rail
No. of Phases	Three-phase
No. of Poles	3P or 4P
Rated Current (A)	5 Maximum 6
Rated Frequency (Hz)	50 / 60
Rated Voltage (V)	3 x 230 (400)
Width in Number of Modular Spacings	5.5

Power & Multifunction Meters

ABB M4M 2X ETHERNET RTS METERDIN MOUNT CLASS 0.54 PROGRAMMABLE I/O M4M 2X ETHERNET RTS
