Product Code: EP-2714

Enhance your automation systems with the Emerson RSTi-EP Digital Output Module. This compact, DIN rail-mounted PLC is designed for distributed slices and offers a high channel density of 4 to 16 points. It supports both positive and negative logic and delivers an output rating of 0.5 to 6A at 24VDC, accommodating 1,2,3, or 4 wire configurations. With dual RJ45 ports, it ensures network redundancy and seamless integration with PROFINET RT, PROFIBUS, Modbus TCP, and EtherCAT protocols. Ideal for machine control, light process control, and general automation tasks within the RSTi-EP series this module streamlines operations in any industrial setting.

Current Consumption	8mA; 20mA + Loads, 20.4-28.8V DC
Maximum Nominal Output Voltage DC (V)	24
Maximum Temperature (°C)	60
Minimum Temperature (°C)	-20
No. of Digital Outputs	4
No. of Ethernet Ports	2
No. of IO	4
Nominal Output Current (A)	6
Rated Maximum Operational Voltage DC (V)	28.8
Rated Minimum Operational Voltage DC (V)	20.4
Redundancy	PNSR
Brand	Emerson
Communication Protocols	MODBUS, PROFINET, PROFIBUS, EtherCAT, EtherNet/IP
Degree of Protection	IP20
Mounting Type	DIN Rail
No. of Output Points	4
Series	RSTi-EP
Standards and Approvals	ATEX/IECeX

Programmable Logic Controllers & I/O

EMERSON RSTI-EP DIGITAL RELAY OUTPUT, 4 POINTS, POSITIVE LOGIC, 24 - 220 VDC/VAC, 6A, 2 WIRE EP-2714

Product Code: EP-2714

Technical Specifications
