RED LION CABLE - CONNECTS TO SLC500 VIA DF1 CBLAB001

Optimize your automation systems with the Red Lion PXU Series PID Controller, available in versatile 1/4 DIN, 1/8 DIN, and 1/16 DIN sizes. This controller offers flexible power connections with AC 100 to 240 VAC or DC 24 VDC options and features universal inputs for precise temperature control. Experience exceptional RTD indication accuracy of (0.3% of span, +1°C) at 25°C and compatibility with a wide range of thermocouple input types including T, E, J, K, R, S, B, N, L, U, and TXK. The unit supports both two or three-wire RTD inputs with an excitation current of 180 µA and accommodates various process inputs from 0-5 or 0-10 VDC to 0-20 or 4-20 mA and even up to 0-50 mV. An optional CT input allows for single-phase AC current monitoring up to 25 mA. Remote input capabilities include ranges from 0-10 VDC to the industry-standard 4-20 mA signal. Communication is streamlined via RS-485 serial interface while output options include time proportioning or DC analog signals. The controller also provides dual relay alarm outputs with Form A or C contacts rated at a robust 3 A @ 250 VAC. Monitoring is made easy with an LCD negative image transmissive display featuring backlighting for clear visibility. Engineered by Red Lion for IO Systems within the realm of Automation Systems, this PID Controller stands out as a reliable solution for precise process control needs.
