Electromagnetic Capability |
10 V/m (80 MHz - 1 GHz), 3 V/m (1,4 GHz – 6GHz) |
|
Electrostatic Discharge (kV) |
4 kV Contact Discharge, 8 kV Air Discharge |
|
Mean Time Between Failure (MTBF) |
3 867 661 h |
|
Operating Voltage |
24V DC |
|
Operating Voltage Range |
24V DC |
|
Port Quantity and Type |
7 x 10/100/1000BASE-TX
3 x 100/1000BASE-FX SFP
1 x Combo (10/100/1000BASE-TX and 100/1000BASE-FX SFP) |
|
Power Output in BTU (IT)/h |
28 |
|
Software Configuration |
Web-based Management, HiDiscovery, Command Line Interface (CLI), Full-featured MIB Support |
|
Software Diagnostics |
Management Address Conflict Detection, LEDs, Device Status Indication, Syslog, Link Speed and Duplex Monitoring, RMON (1, 2, 3, 9), Port Mirroring 1:1, Port Mirroring N:1, System Information, SFP Management |
|
Software Management |
LLDP (802.1AB), LLDP-MED, Password change on first login, SSHv2, HTTP, HTTPS, Responsive GUI, SNMP v1/v2/v3, Traps, Telnet, TFTP, Dual Software Image Support |
|
Software Redundancy |
MRP Client, RSTP 802.1D-2004 (IEC62439-1), ERPS (G.8032), ERPS v2 (G.8032) |
|
Software Security |
MAC Address Limit Per Port, Restricted Management Access, Appropriate Use Banner, Multiple Privilege Levels, Local User Management |
|
Software Switchng |
Static Unicast/Multicast Address Entries, VLAN (802.1Q), Independent VLAN Learning, QoS/Port Prioritization (802.1D/p), TOS/DSCP Prioritization, CoS Queue Management, Queue-Shaping/Max. Queue Bandwidth, Jumbo Frames, IGMP Snooping/Querier (v1/v2/v3), Unknown Multicast Filtering, IGMP Group Filtering per Port, Flow Control (802.3X), Egress Interface Shaping, Ingress Storm Protection |
|
Software Time Synchronization |
NTP Client |
|
Transition Type |
2 kV Power Line, 2 kV Data Line |
|
Brand |
HIRSCHMANN |
|
Approvals |
CE, FCC, EN61131 |
|
Cable Length (m) |
0 - 100 |
|
Degree of Protection |
IP30 |
|
Dimensions (mm) |
68W x 135H x 118D |
|
Mounting Type |
DIN Rail |
|
No. of Pins |
6 |
|
Operational Temperature Range (°C) |
-40 - 60 |
|
Power Consumption (W) |
8.2 |
|
Standards |
CE, FCC, EN61131 |
|
Storage Temperature Range (°C) |
-40 - 85 |
|
Surge Voltage (kV) |
Power Line: 2 kV (Line/Earth), 1 kV (Line/Line), 1 kV Data Line |
|
Terminal Type |
1 x Plug-In Terminal Block |
|
Weight (g) |
680 |
