Product Code: 942 170-999-013

The Hirschmann BOBCAT Series Managed Industrial Switch is a robust networking solution designed for demanding industrial environments. This switch features 12 ports, including 8 Fast Ethernet RJ45 ports supporting 10/100BASE-TX and 4 dual-speed fiber ports with 100/1000Mbit/s capability. It offers flexible uplink connectivity through four SFP slots (2 pairs) that accommodate both 100Mbit/s and Gigabit modules. Engineered for reliability, it operates on dual power inputs ranging from 24 VDC to 48 VDC and 24 VAC, with a low power consumption of just 9W. The device maintains functionality in extreme temperatures from 0 to +60°C and is housed in an IP30-rated enclosure for protection against dust and foreign objects. Installation is made easy with DIN Rail mounting, making the BOBCAT series an ideal choice for engineers looking to maintain network integrity in harsh industrial settings.

Maximum Temperature (°C)	60
Minimum Temperature (°C)	0
No. of 100Mb Ports	8
No. of 1GB Ports	4
No. of Ethernet Ports	8
No. of Fiber Ports	4
Nominal Power (W)	9
Port Quantity and Type	8 x 10/100BASE-TX RJ45, 4 x 100/1000 SFP
Rated Maximum Operational Voltage AC (V)	24
Rated Maximum Operational Voltage DC (V)	48
Rated Minimum Operational Voltage DC (V)	24
Brand	HIRSCHMANN
Degree of Protection	IP30
Dimensions (mm)	138H x 73W x 115D
Mounting Type	DIN Rail
Operational Temperature Range (°C)	0 to +60
Power Consumption (W)	9
Rated Voltage DC (V)	2 x 24
Series	BOBCAT
Standards and Approvals	CE, FCC, EN61131, EN62368-1
Switch Type	Switch - Managed
