RED LION 8 PORT MANAGED ETHERNET SWITCH 708FX2-ST

Product Code: 708FX2-ST

Optimize your industrial network with the Red Lion 1003GX2, a robust 3-port gigabit media converter designed for seamless integration into demanding environments. This unmanaged, multimode fiber converter features an LC style connector and supports a fiber length of up to 550 meters, ensuring reliable long-distance connectivity. With a power input range of 10-30 VDC and a maximum input current of 200mA at 24V, it's engineered for stability. The unit includes one RJ45 TX port for 10/100/1000BaseT connections and two SFP LC duplex ports compatible with 1000BaseSX/LX SFP modules. Part of Red Lion's trusted network solutions in the switches category, this media converter is built to deliver uncompromised performance where you need it most.

Technical Specifications

Current Consumption (mA) 330 at 24VDC
DIN Rail Width (mm) 35
Maximum Temperature (°C) 85
Minimum Temperature (°C) -40
No. of 100Mb Ports 2
No. of Ethernet Ports 6
Rated Maximum Operational Voltage DC (V) 30
Rated Minimum Operational Voltage DC (V) 10
Brand RED LION
Cable Type FX Cable - Multi Mode
Connector Type FX Port - ST
Degree of Protection IP30
Dimensions (mm) 58H x 153W x 96D
Mounting Type DIN Rail
No. of Ports 6 x 10/100BASE-TX RJ45, 2 x 100BASE-FX
Operational Temperature Range (°C) -40 to +85
Rated Operational Voltage DC (V) 10 - 30
Series 1003GX2
Standards and Approvals ATEX/IECeX
Switch Type Switch - Managed
