MERSEN 594.0257 FUSE LINK 25A DIAZED SIZE E16 12.5X50mm GG TYPE

Product Code: 594.0257

The 594.0257 is a European bottle Diazed D type (E16) 12.5 x 50mm fuse link with a utilisation category of gG. It complies with standards such as IEC241, IEC269-3, and DIN-VDEO636. The fuse link has a yellow gauge colour and is rated for a voltage of 500VAC or less. It has a breaking capacity of 50kA and a rated current of 25A.

Technical Specifications

Gauge Colour Yellow
Brand MERSEN
Breaking Capacity AC (kA) 50
Rated Current (A) 25
Rated Voltage AC (V) 500
Body Size (mm) 12.5 x 50
Top Cap Diameter (mm) 14
Utilisation Category gG
Degree of Protection IP20
