MERSEN 594.0167 FUSE LINK 16A DIAZED SIZE E16 12.5X50mm GG TYPE

Product Code: 594.0167

The 594.0167 is a European bottle Diazed D type (E16) fuse link with dimensions of 12.5 x 50mm. It falls under the utilisation category of gG and complies with standards such as IEC241, IEC269-3, and DIN-VDEO636. The fuse link has a grey gauge colour and is rated for a voltage of 500VAC or lower. It has a breaking capacity of 50kA and a rated current of 16A.

Technical Specifications

Breaking Capacity AC (kA) 50
Gauge Colour Grey
Top Cap Diameter (mm) 10
Utilisation Category gG
Brand MERSEN
Body Size (mm) 12.5 x 50
Degree of Protection IP20
Rated Current (A) 16
Rated Voltage AC (V) 500
