SCHMERSAL BPS36-2 SAFETY SENSOR 101191859

Product Code: 101191859

The Schmersal BPS36 series safety sensor features a durable plastic enclosure with an integrated actuator 90. This machine safety component has an actuator length of 88 mm and a width of 25 mm, ensuring compatibility with various machinery setups. Designed for reliable performance, the BPS36 is part of Schmersal's commitment to advanced safety sensors that meet stringent industry standards.

Technical Specifications

Brand SCHMERSAL
eCl@ss Number, Version 11.0 27-27-27-04
eCl@ss Number, Version 9.0 27-27-27-04
ETIM 6.0 EC002549
ETIM 7.0 EC002549
Gross Weight (g) 575
Maximum Actuating Speed (m/s) 0.2
Maximum Fuse Rating 6 A gG D-fuse to DIN EN 60269-1
Minimum Ambient Temperature (°C) -30
Net Weight (g) 955
No. of Safety Contacts 2
Sensor Height (mm) 85
Sensor Length (mm) 46
Switching Element NO contact, NC contact
Switching Principle Slow action
Thermal Test Current (A) 0.25
Utilisation Category DC-12 | DC-13
Utilisation Category AC-15 250 VAC
Utilisation Category DC-13 24 VDC
Contact Material Silver
Degree of Protection IP20
EAN 4030660000000
Enclosure Material Light alloy die-casting
Maximum Ambient Temperature (°C) 50
Maximum Cable Cross Section (mm²) 2.5
Minimum Cable Cross Section (mm²) 0.25
Minimum Mechanical Life 1000000 Operations
Rated Impulse Withstand Voltage (kV) 4
Rated Insulation Voltage (V) 250
Series BPS36
Standards EN IEC 60947-5-1 / EN ISO 13849-1 / BG-GS-ET-15
Terminal Type Screw terminals M20 x 1.5
