ABB POWER SUPPLY DIN 24V DC 0.42A 1 0W CPD24/0.42

Product Code: CPD24/0.42

The CP-D 24/0.42 is a power supply from the CP-D range. The primary switch mode power supply offers a wide range input of 90-264 V AC and 120-375 V DC, rated input voltage is 100-240 V AC. The rated output power is 10 W, rated output current is 0.42 A at an output voltage of 24 V DC. The power supply provides a U/I output characteristic.

Technical Specifications

Frequency Range (Hz) 47 - 63
Input Voltage Range AC (V) 90 - 264
Input Voltage Range DC (V) 120 - 375
Output Power (W) 10
Brand ABB
Degree of Protection IP20
Operational Temperature Range (°C) -40 °C to +70 °C
Output Current (A) 0.42
Output Voltage DC (V) 24
Weight (g) 66
