PFANNENBERG DTS DTS 8441E 400V 2~ CSC 7035 CM, 2000W, IP54 WALL MOUNTED COOLING UNIT 13088491066

Product Code: 13088491066

Explore the Pfannenberg DTS Series Cooling Units, designed for efficient thermal management in industrial environments. These units offer a cooling capacity ranging from 300 to 2500 W, compliant with EN 14511 (A35/A35) standards. They operate on a rated voltage of either 230 VAC with an integrated condensate management system (CM) or a robust 400 VAC 2~ (CM). The DTS series ensures optimal airflow, boasting an internal unimpeded flow of 224 to 1520 m³/h and an external flow rate of up to 1520 m³/h. Engineered for precision control, they maintain temperatures within a range of +25 to +45°C. With an IP54 rating, these units are protected against dust and water ingress, ensuring reliable operation in demanding conditions. Finished in RAL 7035, they blend seamlessly into industrial settings while providing top-tier cooling performance. Trust Pfannenberg's expertise in thermal management to keep your operations cool and efficient.

Technical Specifications

Cooling Capacity (W) 2000
Cover Steel powder coated
Maximum Temperature (°C) 55
Minimum Temperature (°C) 15
Noise Level (dBA) ≤66
Rated Maximum Operational Voltage AC (V) 440
Rated Minimum Operational Voltage AC (V) 360
Rated Operational Power (kW) 2
Starting Current (A) 15
Unimpeded Airflow - External 1340
Unimpeded Airflow - Internal 1000
Brand PFANNENBERG
Ambient Temperature Range (°C) +15 to +55
Colour RAL7035
Current Consumption (A) 5.1
Degree of Protection IP54
Dimensions (mm) 400W X 1350H X 200D
Housing Material Galvanised sheet steel
Mounting Type Door/Side
Power Consumption (W) 784
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 400± 10%
Series DTS
Terminal Type Spring-type
